JP
TurboX-M12M-JP
TurboX-M12M-JP Thundercomm Technology Co., Ltd
- LTE Advanced Category 13 module with GNSS targeted for the Japanese market.
- Rich set of protocols, software features, and industry-standard interfaces including I2C/SPI/PCM/UART /USB/eSIM (optional), etc
- Designed in M.2 Key B form factor
- 2 separate SKUs for with/without built-in eSIM；
- Linux, can work with Windows/Ubuntu/Android host AP
| IOT完了年月 | 2023年3月 |
|---|
| Radio Access technology | 4G/3G | ||
|---|---|---|---|
| Chipset vendor / model | Qualcomm/SDX-12 | ||
| Module FW version | TC-01.M12M-JP.DCM.1.0.0-R037 (TurboxM12MUB30LE10AT254G.R00004) | ||
| IOT completed information | 5G | Availability | NS |
| Supported Band | NS | ||
| 4G | Availability | S | |
| Supported Band | Band 1/3/19/21 | ||
| Category | Cat.7 | ||
| DL CA | 2CC | ||
| UL CA | NS | ||
| 3G | Availability | S | |
| Supported Band | Band I/VI/XIX | ||
| DL Category | Cat.24 | ||
| UL Category | Cat.6 | ||
| Function | CS Voice | NS | |
| VoLTE | NS | ||
| Data | S | ||
| SMS | S | ||
| eDRX | NS | ||
| PSM | NS | ||
| GPS | Standalone | S | |
| Assisted （Control Plane） |
S | ||
| Module information | Interface | USB2.0&USB3.0 | |
| Operation Temperature | -30°C to + 75°C | ||
| Form Factor | M.2 | ||
| Dimension ※L×W×H(mm) | 30 x 42 x 2.3 | ||
| Weight（g） | 6.56g | ||
Update date:2024/11
