JP
L816-GL
L816-GL Fibocom Wireless Inc.
- One World One SKU
- LTE Cat1 Only
- Support Linux
- Support Airplane mode
- Support wake up modem
| IOT完了年月 | 2018年7月 |
|---|
| Radio Access technology | 4G/3G | ||
|---|---|---|---|
| Chipset vendor / model | Intel/XMM7120M | ||
| Module FW version | 18106.5009.02.01.01.20 | ||
| IOT completed information | 5G | Availability | NS |
| Supported Band | NS | ||
| 4G | Availability | S | |
| Supported Band | Band 1/3/19 | ||
| Category | Cat.1 | ||
| DL CA | NS | ||
| UL CA | NS | ||
| 3G | Availability | S | |
| Supported Band | Band I/VI | ||
| DL Category | Cat.8 | ||
| UL Category | Cat.6 | ||
| Function | CS Voice | NS | |
| VoLTE | NS | ||
| Data | S | ||
| SMS | S | ||
| eDRX | NS | ||
| PSM | NS | ||
| GPS | Standalone | NS | |
| Assisted （Control Plane） |
NS | ||
| Module information | Interface | USB 2.0 x 1 | |
| Operation Temperature | -10°C ～ +55°C | ||
| Form Factor | LGA | ||
| Dimension ※L×W×H(mm) | 21mm × 30mm × 1.55mm | ||
| Weight（g） | 2.494 ～ 2.52g | ||
Update date:2024/11
